More please contact us :+86 731 85220692 +86 731 13319545642 info@zanchen-parts.comF24-60 joystick radio remote control, tower crane remote controller, Schwing remote control 1.More than 10 years researching and exporting experience in Radio Remote Control industry. 2. Well and high quality control, all working process according to ISO9001:2008. 3. CE, FCC & ISO certificates. 4. One year warranty. 5. Sample order acceptable. 6. OEM acceptable Specification: Control distance | Up to 100m | Control point | 40 | Certificates | CE, FCC, ISO | Unique code | Over 4.3billon unique ID codes . | Working temperature | -35°C___+80°C | Enclosure protection class | IP65 | Transmitter power | DC3v | Receiver power | AC 380v/ 36v/220V or DC12V/24V | Output capacity | Full sealed relay output with 5 amperes |
Brief Introduction: Transmitter Size:200*110*90mm weight:860g Receiver Size:290*230*70mm weight:2200g Standard configuration: One transmitter ; One receiver; One 3m cable connect with receiver One operation and maintain manual . Products Features: 1. With ratio module,analog signals can be output (additional costs). Ratio output: standard 0-10V 2. 2 five steps of 10 million times mechanical life Pure proportion joystick without fault of poor contact 3. 6 function keys 4. Three positions/tow positions rotating switches 5. Light weight and neck hanging design for Asian ergonomics 6. With 3 steps battery voltage alarm device, the power is cut off during low power 7. Safety key switch 8. Enhanced watch-dog circuit with automatically stop device 9. Signal search and frequency automatic tracking circuit 10. Prevent power from sudden breaking 11. Programmable relays outputs 12.3 super heterodyne receiving circuits 13. LED and indicator outputs 14. Variety functions and parameters can be set by computer interface 15. Setting free up to users requirements *Durable nylon-fiber housing for extra shock resistance. *Fully programmable relay configuration with maximum 16 relays output per command. *Operating range up to 100 meters. *Pre-wiring standard cable making installation quick and easy. *Economic efficiency, ease of operation. *3 stages LED battery power indicator. *Feature acceleration delay time control (smooth moving for multiple speeds cranes).

| Transmitter | Receiver | | Frequency | 430~440MHz | | Max Output Power | 10dBm | Sensitivity | -116dBm | | Distance | 500M | Power dissipation | <5W | | Coding number | 4200000000 | | Impedance | (Built-in) , 50Ω | | Protection class | IP64 | Protection class | IP65 | | Shell material | ABS | | Working temp | -20°C ~ +70°C | Working temp | -30°C ~ +70°C | | Supply Voltage | DC3V(AA*2) | Supply Voltage | 36V/220V/380V AC 50Hz/60Hz
*customizable* | | Operating current | <1mA | | Relative humidity | 90% RH | | Atm | 86-106KPa | | Field conditions | Surrounded by strong vibration, strong electromagnetic field |
Any requirements or question,welcome to "SEND"us an e-mail Now!!! |
