32 001690201A0000002 0167502A0021 过渡套 Bush 2
33 1040000484 GB/T5782-2000 螺栓 M16×120-8.8 Bolt 10
34 1040300065 GB/T93-1987 垫圈 16 Washer 14
35 1081000458 GB/T3452.1-1992 O 形密封圈 250×5.3 O ring 2
36 000190201A0000013 0167502A0003 摇臂 Rocker 1
37 1040000114 GB/T5783-2000 螺栓 M10×25-8.8 Bolt 2
38 1040300067 GB/T93-1987 垫圈 10 Washer 2
39 000190201A0000022 0167502A0006 螺母 M80×3 Nut 1
40 000190201A0000023 0160402A0012 挡块 Block 1
41 1040000098 GB/T5783-2000 螺栓 M8×16-8.8 Bolt 8
42 000190201A0000017 0160402F0026 限位板 Baffle 4
43 000190201A0000029 0167502A0014 键 Key 2
44 1040100348 GB/T70.1-2000 螺钉 M4×12-8.8 Screw 2
45 1040300044 GB/T93-1987 垫圈 4 Washer 2
46 000190201A0000024 0167502A0005 轴套 Bush 1
47 1081000429 GB/T3452.1-1992 O 形密封圈 95×2.65 O ring 2
48 000190201A0000025 0167502A0004 垫套 Bush 1
49 000190201A0000028 0167502A0013 螺堵 Block 3
50 000190201A0000027 0167502A0011 定位销 Pin 1
51 001690201A0000009 0167502A0012 垫圈 Washer 1
52 1040100381 GB/T70.1-2000 螺钉 M16×50-8.8 Screw 6
53 000190201A0000026 0160402A0010 端面轴承 Bearing 1
54 000190201A0200000 0160402F9000 左摆动油缸 Cylinder 1
55 000190201A0000021 0167502A0020 轴承座 Bearing carrier 1
56 1081000442 GB/T3452.1-1992 O 形密封圈 106×3.55 O ring 1
57 000190201A0000033 0160402A0011 挡圈 Gasket 1
58 000190201A0000032 0160402A0008 DU 轴承 Bearing 1
59 000190201A0000031 0160402A0015 Yx 型密封圈 d105 Gasket 1
60 000190201A0000030 0160402A0016 J 型防尘圈 d105 Gasket 1
61 1081000551 GB/T3452.1-1992 O 形密封圈 125×5.3 O ring 1
62 001690201A0201000 0167502A2100 S 管阀 S tube 1

63 000190201A0000020 0167502A2001 活动刮板 Plate 1
64 1040000149 GB/T5783-2000 螺栓 M12×50-8.8 Bolt 2
65 1040200096 GB/T6170-2000 螺母 M12-8 Nut 2
66 001690201A0000010 0167502A0015 销轴 Pin 1
67 1040500217 GB/T91-2000 开口销 8×63 Pin 1
68 000190201A0100001 0010302A0013 轴套 Bush 1
69 001690201A0000011 0167502A0016 斜块 Block 1
70 000190201A0000011 0010202A0006 套 Bush 1
71 000190201A0300001 0160402F5001 活塞杆 Piston rod 1
72 1040100482 GB/T77-2000 螺钉 M8×12 Screw 1
73 1081200129 A1 型防尘圈 Wiper 1
74 1081000493 BS 活塞杆密封 Piston rod seal 1
75 1081400502 FR 型活塞杆导向环 Guide ring 1
76 1040100343 GB/T70.1-2000 螺钉 M12×25 Screw 14
77 1040300054 GB/T93-1987 垫圈 12 Washer 14
78 000190201A0300002 0160402F5002 导向套 Guide muff 1
79 1081000434 GB/T3452.1-1992 O 形密封圈 37.5×3.55 O ring 1
80 000190201A0300003 0160402E4002 挡圈 φ90×84.5×1.5 Gasket 2
81 1081000439 GB/T3452.1-1992 O 形密封圈 82.5×3.55 O-Ring 2
82 1081400511 FR 型活塞导向环 Guide ring 2
83 1081000506 OK 型活塞密封 Piston ring 1
84 000190201A0300007 0160402F5006 活塞 Piston 1
85 000190201A0301000 0160402F5100 油缸体 Cylinder body 1
86 1010300514 单向阀 Valve 1
000190201A0300004 0160402F6005
87
000190201A0200001 0160402F9005
缸头法兰
Flange 1
88 1081000424 GB/T3452.1-1992 O 形密封圈 8×1.8 O ring 1
89 000190201A0300005 0160402F6004 锁紧螺母 Nut 1
90 000190201A0300006 0160402F6003 调节螺栓 Bolt 1
