1 001607103A0210000 0167181A2100 左前支腿结构 Left outrigger 1
2 1040000511 GB/T5782-2000 螺栓 M24×70-10.9 Screw 4
3 1040300050 GB/T97.1-2002 垫圈 24-200HV Gasket 4
4 001607104A0300000 0167197A1000 前支腿垂直油缸 Hydraulic cylinder 1
5 001607103A0300001 0167181A1001 轴 φ30×202 Pin 1
6 001607103A0300002 0167181A1002 盖板Ⅰ t5 Plate Ⅰ 2
7 1040100021 GB/T819.1-2000 十字槽沉头螺钉 M5×16-4.8 Screw 8
8 001607104A0800000 0167196A2000
右前支腿水平伸缩油缸 Hydraulic cylinder 1
9 001607103A0300003 0167181A1003 垫圈 t8 Gasket 2
10 001607103A0300004 0167181A1004 托轮Ⅰ Wheel Ⅰ
2
11 001607103A0300005 0167181A1005 盖板Ⅱ t9 Plate Ⅱ
2
12 001607103A0300006 0167181A1006 轴 φ20×118 Pin
1
13 001607103A0300007 0167181A1007 托轮Ⅱ Wheel Ⅱ
2
14 1040500219 GB/T879.4-2000
销 φ5×30 Pin 2

1 001607103A0510000 0167182A1100 右后支腿结构 Right rear outrigger 1
2 001605103A0100001 0161551C0003 进水口螺帽 Cover 1
3 1019900074 YWZ-400 液位计 Liquid meter 1
4 1081000575 GB/T3452.1-1992 O 形密封圈 190×3.55 O-ring 2
5 001607103A0500001 0167582B0002 法兰盖 Flange cover 2
6 1040100154 GB/T70.1-2000 螺钉 M10×16-8.8 Screw 12
7 1040000507 GB/T5783-2000 螺栓 M24×70-10.9 Bolt 4
8 1040300050 GB/T97.1-2002 垫圈 24-200HV Washer 4

1 001607103A0410000 0167182A2100 左后支腿结构 Right rear outrigger 1
2 001605103A0100001 0161551C0003 进水口螺帽 Cover 1
3 1019900074 YWZ-400 液位计 Liquid meter 1
4 1081000575 GB/T3452.1-1992 O 形密封圈 190×3.55 O-ring 2
5 001607103A0500001 0167582B0002 法兰盖 Flange cover 2
6 1040100154 GB/T70.1-2000 螺钉 M10×16-8.8 Screw 12
7 1040000507 GB/T5783-2000 螺栓 M24×70-10.9 Screw 4
8 1040300050 GB/T97.1-2002 垫圈 24-200HV Washer 4
