1 1010600033 吸油过滤器 Suction filter 1
2 1010000086 臂架油泵 Oil pump of boom section 1
3 1010600041 压油过滤器 Delivery oil filter 1
4 1140101574 压力表连接测试点接头 Pressure measuring joint 1
5 1010300519 T 口背压阀 Compensation valve 1
6 001607150A0010000 多路阀总成（六联）
multi-passage directional
selecting valves
1
7 1010300537 回转缓冲制动阀
Slewing and cushioning
control valve
1
8 1010300634 平衡阀 Counterbalance Valve 8
9 1010300542 单向阀 Check valve 1
10 1010300648 铰接螺栓 Bolt 7
11 1010300649 铰接螺栓 Bolt 1

1010300687 多路换向阀
multi-passage directional
selecting valves
1
2 1010300616 多路阀片 multi-passage valve 1
3 1010300576 多路阀片 multi-passage valve 1
4 1010300769 多路阀片 multi-passage valve 2
5 1010300770 多路阀片 multi-passage valve 2
6 1010300584 终端块 End plate 1

1 001607149A0000001 0167149A0002 隔壁板 Plate 1
2 001607149A0000002 钢管 Φ10×2-L=1200 Steel pipe 1
3 001607149A0000003 钢管 Φ18×3 Steel pipe 1
4 001607149A0000004 钢管 Φ16×2.5-L=615 Steel pipe 1
5 001607149A0000005 钢管
Φ16×2.5-L=650 Steel pipe 1
6 001607149A0000006 钢管 Φ12×2 Steel pipe 1
7 001607149A0001000 一节臂布管图 Pipeline of 1st boom 1
8 001607149A0002000 二节臂布管图 Pipeline of 2nd boom 1
9 001607149A0003000 三节臂布管图 Pipeline of 3rd boom 1
10 001607149A0004000 一节臂油缸布管图 Pipeline of 1st cylinder 1
11 001607149A0005000 二节臂油缸布管图 Pipeline of 2nd cylinder 1
12 001607149A0006000 三节臂油缸布管图 Pipeline of 3rd cylinder 1
13 001607149A0007000 四节臂油缸布管图 Pipeline of 4th cylinder 1
14 001605149A0000016 0165149D0007 棉织胶管 φ18-800 House 1
15 001605149A0000005 18V.10-4 放水接头 Joint 3
16 001605149A0000004 W18B-39 接头体 M22×1.5/R3/8 Joint 3
17 000198930A0100016 0160149B0004 端直通接头 M27×2//M26×1.5 Joint 2
18 000198931A0100004 0160149A0003 端直通接头 G1/M24×1.5 Joint 2
19 001605149A0000001 0165049B0001 臂架泵进口接头 Joint 1
20 001605149A0090000 0165149D0200 臂架泵吸油接头 Joint 1
21 001605149A0080000 0165149D0100 臂架吸油过渡法兰 Flange
1
22 000198930A1000011 0160149A0010 阻尼接头 M10×1/M14×1.5 Joint
1
23 1140101438 SV15LOMDCF 直通隔板式接头 M22×1.5 Bulkhead joint 8
24 1140101464 GE15LREDOMDCF 端直通接头 G1/2/M22×1.5 Joint 16
25 1140101461 GE10LREDOMDCF 端直通接头 G1/4/M16×1.5 Joint 2
26 1140101466 GE18LR3/4EDOMDCF 端直通接头 G3/4/M26×1.5 Joint 1
27 1140101470 GE16SR3/4EDOMDCF 端直通接头 G3/4/M24×1.5 Joint 1
28 1140101529 GE12SR1/4EDOMDCF 端直通接头 G1/4/M20×1.5 Joint 1
29 1140101452 GE10LM16×1.5EDCFX 端直通接头 M16×1.5 Joint 3
30 1140101463 GE12LR1/2EDOMDCF 端直通接头 G1/2/M18×1.5 Joint 2
31 1140101448 GE12LMEDOMDCF 端直通接头 M16×1.5/M18×1.5 Joint 1

32 1140101462 GE12LREDOMDCF 端直通接头 G3/8"/M18×1.5 Joint 1
33 1140101631 GE10LM12×1.5EDCFX 端直通接头 M12×1.5/M16×1.5 Joint 1
34 1140101511 W10LCFX 直角接头 M16×1.5 Joint 2
35 1140101431 W16SCFX 直角接头 M24×1.5 Joint 2
36 1140101476 EW10LOMDCF 直角组合接头 M16×1.5 Joint 1
37 1140101482 EW12SOMDCF 直角组合接头 M22×1.5 Joint 1
38 1140101483 ET12LOMDCF 三通组合接头 M18×1.5 Joint 1
39 1140101433 RED10/06LOMDCF 对接式变径接头 Joint 2
40 1140101435 RED12/08LOMDCF 对接式变径接头 M18×1.5/M14×1.5 Joint 1
41 1990200037 No.1 19-29 喉箍 Hoop 3
42 1010300520 球阀 G3/8 Ball valve 3
43 1140101425 G12LCFX 直通接头 M18×1.5 Joint 2
44 1140101665 G18LCFX 直通接头 M26×1.5 Joint 1
45 1140101562 FHS62CFX SAE 1/2 高压法兰片 Flange 1
46 1140101492 GFS62/16SCFX SAE 高压 1/2 法兰式接头 Flange joint 1
47 1081000485 DRV100196 菱形密封圈 22 Rhombus-seal t 3
48 1081000481 DRV100138 菱形密封圈 16 Rhombus-seal 3
49 1081000486 DRV100239 菱形密封圈 27 Rhombus-seal 2
50 1081000487 DRV100297 菱形密封圈 33 Rhombus-seal 2
51 1081000479 DRV100098 菱形密封圈 12 Rhombus-seal 1
52 1081000478 DRV100084 菱形密封圈 10 Rhombus-seal 1
53 1140101588 M10LCFX 螺母 M16×1.5 Nut 2
54 1140101496 PSR10LX 卡套 Cover 2
55 1140101586 M12LCFX 螺母 M18×1.5 Nut 2
56 1140101497 PSR12LX 卡套 Cover 2
57 1140101587 M18LCFX 螺母 M26×1.5 Nut
2
58 1140101495 PSR18LX 卡套 Cover
2
59 1140101590 M16SCFX 螺母 M24×1.5 Nut
4
60 1140101499 PSR16SX 卡套 Cover
4
61 1140101574 VKA3/12SCF 压力表连接测试点接头 M20×1.5 Test coupling
1
62 1040000018 GB/T5783-2000 螺栓 M8×30 Bolt
2

63 1040000069 GB/T5783-2000 螺栓 M12×25 Bolt 2
64 1040300054 GB/T93-1987 垫圈 12 Washer 6
65 1040100073 GB/T70.1-2000 螺钉 M8×30 Screw 4
66 1040300063 GB/T93-1987 垫圈 8 Washer 6
67 1040100071 GB/T70.1-2000 螺钉 M10×25 Screw 8
68 1040300067 GB/T93-1987 垫圈 10 Washer 8
69 1040100122 GB/T70.1-2000 螺钉 M8×25 Screw 6
70 1040300066 GB/T97.1-2002 垫圈 8 Washer 6
71 1040100054 GB/T70.1-2000 螺钉 M12×35 Screw 4
72 1081000473 2-210 O 形密封圈 18.64×3.53 O-ring 1
73 1081000472 2-214 O 形密封圈 25×3.53 O-ring 1
74 1081000475 2-225N552-90 O 形密封圈 47.22×3.53 O-ring 1
75 1081000522 GB/T3452.1-1992 O 形密封圈 140×3.55 O-ring 1
76 1990200302 TTPG16-110 双联管夹 Clamp 2
77 1990200157 TLPG3-218 管夹 φ18 Clamp 2
78 1990200081 TLPG3-216 管夹 φ16 Clamp 4
79 1990200049 TLPG3-112 管夹 φ12 Clamp 1
